| Quantity: | |
|---|---|
Granule Horizontal Feeding Bag Product Advantage |
With a built-in high-efficiency dust collector (airflow rate: 200m³/h), our machine removes airborne particles generated during the filling process. This ensures a clean workspace, adhering to FDA and EU 10/2011 food safety standards. The washable filter can be reused up to 50 times, reducing operational costs while maintaining hygiene, which is especially critical when packing coffee packet machines and milk powder sachet packaging machines.
The machine comes equipped with three high-sensitivity load cells, offering a weighing range of 50-2000g with an accuracy of ±0.1g. This ensures that each package has precise fill weights, reducing the risk of overfilling or underfilling, and making the system perfect for products like granule packing machines and tea bags machine packaging. The dual-stage dosing system (coarse and fine dosing) ensures precise filling even with irregularly shaped products like coffee, tea, and milk powder.
The machine supports a variety of bag types, such as gusseted bags, zipper bags, and eco-friendly paper-plastic composite bags. An optional nitrogen flushing system (purity ≥99.99%) is available to extend the shelf life of oxygen-sensitive products like instant coffee packets, roasted coffee beans, powdered milk, and herbal supplements. This feature makes it the perfect automatic packaging machine for coffee.
Whether you need high-speed packing machines for large batches or automatic bag packing machines for smaller volumes, this system delivers superior performance. The packing speed can reach up to 30 packets per minute, making it an excellent choice for manufacturers who need quick and efficient coffee packaging machines and tea bagging machines.
Designed with user-friendliness in mind, the coffee packet machine allows for easy setup, operation, and cleaning. With an automatic bag packing machine function, you can load, fill, and seal the product seamlessly. The machine's anti-blockage design reduces downtime, and the routine maintenance (e.g., cleaning the hopper, lubricating the vibratory system) is quick and easy to perform.
Technical Parameters |
| Model | AH-SPM-K200 |
| Making bag size | (L)100-280mm (W)80-200mm |
| Packing Speed | 1-30 packets/min |
| Filling Range | 2~1000g |
| Air consumption | 0.7 m3 / min |
| Power Supply | 220V 50HZ |
| Measuring accuracy | ≤±1.2% |
| Packing material | Paper/PE, PET/AL, Foil/PE Nylon/PE, Tea-leaf filtering paper, etc. |
| Weight | 400KG |
| Dimension | 1000*700*1420MM |
Product Uses |
Ideal for packaging granular products in industries with diverse material characteristics:
• Food Industry: Snack nuts (almonds, cashews), popcorn (buttered or caramelized), sugar (granulated or caster), salt (iodized or sea salt), cereal grains (oats, quinoa), and instant noodle seasoning packets (small-dose granular spices).
• Agriculture: Seeds (vegetable, flower, or crop seeds with anti-caking treatment), fertilizers (water-soluble granular types), and animal feed pellets (e.g., chicken feed with added vitamins, fish food granules).
• Chemicals: Detergent granules (laundry or dishwashing), water treatment additives (activated carbon, ion exchange resins), resin pellets (for plastic manufacturing), and fertilizer additives (trace element granules).
• Pharmaceuticals: Herbal granules (traditional Chinese medicine extracts), effervescent tablets (uncoated or film-coated), and dietary supplement granules (protein powder, multivitamin blends).
High-Speed Performance: Capable of handling up to 30 packets per minute, making it ideal for large-scale operations requiring fast and efficient automatic coffee packaging machines.
Precision and Reliability: The precise weighing system ensures consistent product packaging with a high level of accuracy, essential for products like coffee, milk powder, and tea.
Dust-Free, Clean Operation: The built-in dust collector and enclosed filling chamber prevent contamination, making the machine suitable for sensitive products like tea bag filling machines and instant coffee mix packaging.
Versatile Bagging Options: Supports various bag types, including gusseted, zipper, and eco-friendly bags, giving you flexibility in packaging for different market needs.
Product Operate Guide |
1. Turn on the power switch.
2. Check whether the air pressure is sufficient (must reach the standard requirements).
3. Click the host to start, and check whether each action is working properly.
4. Check and clean up each box room.
5. Put the bag, load the material, put the material box.
6. Click the host to start.
7. The product that is packaged in vacuum for the first time should be checked whether the seal is firm, whether the suction is tight and through the water check(Must check vacuum chamber 1-10).
8. During the production process, check the product sealing and pumping conditions continuously.
9. Every 2 hours after the machine runs, must be the top cover of the machine, bag clip, and funnel mouth, carried out with an air gun clean.
10. The bag or material dropped on the machine, should be hooked out with a hook, do not take it by hand.
FAQ |
Q: What is the maximum particle size it can handle, and does it work with sticky or cohesive granules?
A: It efficiently packages granules up to 8mm in diameter, including irregularly shaped products like lentils, chickpeas, and broken nuts. For sticky or cohesive granules (e.g., brown sugar, powdered cocoa with fat content), the machine’s anti-stick hopper (coated with Teflon) and vibratory feeding system (adjustable frequency) prevent clumping, ensuring smooth flow.
Q: How does it prevent bag blockages, and what maintenance is needed for the feeding system?
A: The anti-stick hopper (with a 60° incline to promote material flow) and vibrating feeding system (with adjustable amplitude) ensure continuous flow, reducing downtime from blockages. Routine maintenance for the feeding system includes weekly cleaning of the hopper (to remove residual material) and monthly lubrication of the vibrator’s bearings (using food-grade lubricant). The machine’s control panel also includes a “blockage alert” function that pauses operation if flow is interrupted, protecting the system from damage.
Q: Can it print batch codes on bags, and what information can be included?
A: Yes, an optional thermal transfer printer (resolution 300DPI) can be integrated to print batch codes, production dates, expiration dates, and QR codes (for product traceability). The printer uses heat-resistant ribbons (compatible with plastic, laminate, and paper bags) and can print text sizes from 2mm to 12mm, ensuring legibility for both small and large bags. The printer’s settings (e.g., print position, speed) are synchronized with the machine’s control system for accurate alignment.
